L28
Small Articulated Loader
L28 Small Articulated Loader
The L28 Bobcat® small articulated loader delivers big performance and heavy lifting in a small package.
- Easily works inside fenced-in landscapes, pens, backyards and more.
- Impressive lifting capacity and telescoping lift arm
- Tight-turning articulation joint
Starting at $47,789 USD*
Pay as low as 0% for 48 months* or choose a $2,500 USD*/$3,300 CAD* rebate on a L28 small articulated loader.
L28 Overview
- The Bobcat® L28 small articulated loader is a compact machine that easily works inside fenced-in landscapes, pens, backyards and more.
- Offers impressive lifting capacity and a telescoping lift arm for added reach.
- Its tight-turning articulation joint improves maneuverability while the nimble design offers a light footprint for minimal damage to turf.
L28 Key Specifications
L28
Horsepower
24.8 hp
Rated Operating Capacity Straight (ISO)
1,534 lb
Rated Operating Capacity Art. (ISO)
1,222 lb
Operating Weight
4195 lb
Auxiliary Std Flow
12.1 gal/min
Width (over tires)
46.5 in
Engine
L28
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
24.8 hp
Turbocharged Engine
no
Performance
L28
Rated Operating Capacity Straight (ISO)
1,534 lb
Rated Operating Capacity Art. (ISO)
1,222 lb
ROC with Counterweight Option Straight
1952 lb
ROC with Counterweight Option Art.
1475 lb
Tipping Load Straight
3068 lb
Tipping Load Art.
2444 lb
Operating Weight
4195 lb
Travel Speed
8.3 mph
Capacities
L28
Fuel Tank
9.6 gal
Hydraulic System
L28
System Relief @ Quick Couplers
2,900 psi
Auxiliary Std Flow
12.1 gal/min
Drive System
L28
Drive Type
Hydrostatic drive with 4 individual drive motors
Dimension
L28
Length
122.4 in
Length without Attachment
93.2 in
Length with Standard Bucket
122.4 in
Width (over tires)
46.5 in
Width (with bucket)
50 in
Height with Operator Cab
78.1 in
Height to Bucket Hinge Pin Ext
104.3 in
Height to Bucket Hinge Pin Ret
85.4 in
Max Reach
30.9 in
Turning Radius Inside
78.2 in
Turning Radius Outside
100.9 in
Wheelbase
47.2 in
Articulation Angle
43°
Dump Angle @ Maximum Height
40°
Ground Clearance
5.5 in
Rollback Angle
32°
Tire Size
23X10.5-12, 8 PLY
Wheel Tread
36.4 in
Features
L28
Air Conditioning
Not Applicable
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Cab Heater
Optional
Operating Lights
Optional
Rear Window
Optional
Lift-Arm Support
Standard
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Not Applicable
Hydraulic Bucket Positioning
Standard
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Horn
Standard
Front and Rear Work Lights
Standard
Rotating Flashing Beacon
Optional
Turn Signals
Optional
Tires-Ply Rating
8
Heavy-Duty Float Tires
Optional
Cup Holder
Standard
Grab Handles
N/A
