E165
Large Excavator
E165 Large Excavator
The E165 large excavator brings you optimized performance for heavy digging and lifting on the job site.
- Class-leading hydraulics
- Features that make daily maintenance quick and easy
- Conventional tail swing for leading lift capacity
Choose 0% financing for 48 months* plus a $6,000 USD*/$7,800 CAD* rebate or receive a $15,000 USD*/ $19,500 CAD* cash rebate in lieu of financing on the E165 large excavator.
E165 Overview
- The turbo-charged Bobcat® E165 large excavator provides optimized performance for heavy digging and lifting operations.
- Class-leading hydraulics give operators reliable power to save time with every digging cycle, while wide-open access panels, a hinged belly pan and centralized grease banks make essential daily maintenance quick and easy.
- Operators also benefit from four power modes and fast cycle times, while side and rear view cameras come standard.
- This 131-hp excavator, in the 16- to 18-ton size class, is ideal for roadways, railroads, bridges, infrastructure and commercial and urban jobsites.
- More slewing torque means increased power for slewing, backfilling and all-around better productivity.
- Comfort features, including a pressurized cab with sound-isolating seal, heated seat and automotive-style heating and air conditioning, keep you comfortable and productive during even the longest workdays.
E165 Key Specifications
E165
Operating Weight
38,376 lb
Bucket Digging Force
25,794 lbf
Maximum Reach at Ground Level
345.6 in
Width
102 in
Tail Swing Type
Conventional
Engine
E165
Emissions Tier (EPA)
Tier 4
Engine Fuel
Diesel
Turbocharged Engine
yes
Optional Turbocharged Engine
N/A
Performance
E165
Operating Weight
38,376 lb
Weight Class
17 t
Travel Speed - High
3.1 mph
Travel Speed - Low
1.9 mph
Arm Digging Force
18,077 lbf
Bucket Digging Force
25,794 lbf
Maximum Dig Depth
240 in
Max Dump Height
255.6 in
Maximum Reach at Ground Level
345.6 in
Capacities
E165
Fuel Tank
77.1 gal
Hydraulic System
E165
Auxiliary Pressure
4,694 psi
Total Hydraulic Flow
80.4 gal/min
Dimension
E165
Length
325.2 in
Width
102 in
Height
120 in
Height with Operator Cab
115.2 in
Features
E165
Air Conditioning
Standard
Cab Enclosure
Standard
Heater Air Conditioning
Standard
Radio
Standard
Tail Swing Type
Conventional
Auxiliary Hydraulics
Standard
Quick Tach System
Optional
Rubber Track
Not Applicable
Selectable Auxiliary Hydraulic Flow
Standard
Dozer Blade
Not Applicable
